SPECIFICATIONS

Brand Name: RETEVIS

Battery Capacity(mAh): 2500

Origin: Mainland China

Waterproof / Water-Resistant: IP68

Maximum Range: 3km-5km

Model Number: RA89

Is_Display: Yes

Walkie Talkie Type: Portable

Output Power(w): 5w-10w

Storage Channel: 200

Frequency Range: USA version 144-148/420-450MHz ,or, EU version 144-146/430-440MHz

Certification: CE

Certification: FCC

Operating Voltage: 7.4VDC

Weight: 320g(battery and antenna included)

Dimension: 126x62x43mm (without antenna)

Modulation Type: FM

Channel Spacing: 12.5/20/25 kHz

Charging Way: USB C Charging

Waterproof Level: IP68 Waterproof

Antenna needed: SMA-M connector

Retevis RA89 High Power Dual Band IP68 Waterproof Ham Radi

Please Know Before Purchasing:

Due to firmware upgrade, for the RA89 walkie talkie with the latest version of firmware, or , you upgrade your RA89 walkie talkie into the latest firmware, you need press SK2( side key 2 ) + Button 9 at the same time and turn on it to extend frequency range.

This method can be applied to firmware verison published after <RA89_Eng_Upadat_20230826_B91.20>.

If it doesn't work, then you perhaps need press button F + 4 at the same time and turn on to extend frequency.

Any question ,please remember to contact us for a slolution.

How to extend the default frequency range of RA89 into full frequency range(VHF 136 - 174 MHz, and, UHF 400 - 480 MHz)?

Instruction to extend frequency range for RA89 of USA verison:

Turn off your RA89 walkie talkie.In the status of shutdown, press[F] button and [4] number button at the same time and turn on it.

If you would like to narrow its frequency into default frequency, please turn off it, press [SK2] side key 2 and [7] number button at the same time and turn on it again.

Instruction to extend frequency range for RA89 of European verison:

Turn off your RA89 walkie talkie.In the status of shutdown, press[F] button and [4] number button at the same time, and turn on it.

If you would like to decrease its frequency into default frequency, please turn off it, press [SK2] side key 2 and [*Lock] button at the same time, and turn on it again.

Tip:

Click the picture below to download the driver of USB programming cable and programming software for RA89.

Any questions, please be free to contact us.

Describe:

1.Ultra-High Power support a good QSO communication;

2.IP68 High-level waterproof performance escorts your calls under harsh conditions;

3.USB-C Charging charging: supports wall charging, mobile power charging, car

charging and computer.

4.Noise Cancellation function ensures you have a clear communication quality.

Function:

1.Dual Band Dual Wait Dual Standby

2.One Key Frequency Pair

3.Noise Cancellation

4.200 Channels

5.Multi Charger way: USB-C Desk Charger / Type C

6. 2 Tone / 5 Tone

7.CTCDD/DCS Scan

8.FM Broadcast

9.Built-in flashlight

The new model walkie talkie RA89 is designed for amateur radio operators. It is applied on many occasions, such as fishing, hunting, etc. With IP68 waterproof function, the walkie talkie can withstand the harsh environments. High power function enables the walkie talkie to communicate over long distance.

IP68 Waterproof

RA89 waterproof walkie talkie allows you to keep a connection whether you are on land or at sea. IP68 rating enables the RA89 walkie talkie to withstand constant submersion of up to 1 meter for 1 hour and withstand severe weather.10W High power

RA89 High power walkie talkie allows you to achieve long-distance communication with your partners or family. Different communication distances offer you more choice. Intelligent Noise Reduction

Built-in with a noise reduction chip, RA89 have a noise filtering feature that can reduce unwanted noise and help in effective communication.USB-C Charging

USB-C is a versatile and efficient charging option that is suitable for a wide range of devices, including smartphones, laptops, tablets, and other electronics. RA89 is also equipped with a charging base for more stable charging.Large Battery Capacity

Powered by a 2500mAh Li-ion battery, RA89 ham radio has a long-lasting battery life and supports all-day use. There is no need to frequently charge the radio when you are outdoors.Easy to Pair

In VFO mode, long press the A/B key, you can quickly identify the scanned signal, copy and save the frequency and CTCSS/DCS. It is more efficient to decrypt and faster to scan.Dual Band/Dual Standby

With 2m/70cm dual band, RA89 can meet different use environments. You can use its UHF band to get stronger penetration power when you are in the city. You can use its VHF band to maximum the use effect when you are outdoors.Scramble Encryption

The scrambler function is efficient in avoiding eavesdropping through changing or mixing the voice and information during the transmission. It ensures your communication privacy when you want to communicate with your teammates privately.Programmable VFO

VFO mode provides great convenience for editing the frequencies and CTCSS/DCS anytime and anywhere. In addition, you can save them as a regular channel to meet daily use.

Emergency Alarm

You can turn on the function by pressing “F” Key and “# Radio” Key (in turn) to ask the people near you for help in the event of an emergency.FM Radio 65-108 MHz

With FM radio, RA89 allows you to enjoy yourself in your spare time. In addition, dual watch function makes it easy to receive the call while you are using the FM radio function.Various ApplicationsSpecificationPackage Includes

Standard Accessories of Package(1pc):

1X RA89 Walkie Talkie

1X 2500mAh Battery

1X Belt Clip

1X Antenna

1X Sling

1X USB-C Charging cable

1X Charging Base

1X User Manual

* Optional Accessories:

1X Programming Cable

1X IP54 Waterproof Speaker Microphone

Standard Accessories of Package(2pcs):

2X RA89 Walkie Talkie

2X 2500mAh Battery

2X Belt Clip

2X Antenna

2X Sling

2X USB-C Charging cable

2X Charging Base

2X User Manual

* Optional Accessories:

1X Programming Cable

2X IP54 Waterproof Speaker Microphone

* If you need optional accessories above,Please purchase the corresponding package option including these accessories.
