FNIRSI WD-01 Metal Detector Wall Scanner Product Manual:

https://www.mediafire.com/file/f1ybsne76pn7gm3/WD-01.pdf

Product testing and evaluation：

https://www.youtube.com/watch?v=b4bTlgPqpwA

----- Or scan & click the QR code to watch the video.

This wall detector scanner can help you to quick locate edges and center metal, studs, joists, pipes and live AC wire behind walls, floors and ceiling. This tool can be widely used in your home decoration, household appliance installation and so on.

Features:
Portable Size: The small size of this tool is very convenient for everyday use, you can also easily hold it while using it.
This wall detector scanner can help you to quick locate edges and center metal, studs, joists, pipes and live AC wire behind walls, floors and ceiling. The measuring ranges of wooden is ≤38mm, AC wires ≤40mm, metal pipes ≤100mm and rebars ≤120mm.
The HPC detection module can makes this wall detector scanner with better anti-interference capacity and fater calculating speed.
Multiple predictions: The screen will display the target depth, arrive at the detection center and the material, the indicator light will lights up yellow or red depending on the target distance, the green light means No traget.
It will also beep when a target is detected. It will continuous alerts when reaching the center.
Wide Applications: This tool can be widely used in your home decoration, wall decoration, household appliance installation, highway maintenance and so on.
Center positioning hole design, you can directly mark the drilling position after detection and achieve precisions drilling.

Specifications:
Material: ABS
Max. detection depth:
Metals: 120mm
Non-ferrous metals(copper): 100mm
AC wire: 50mm
Single-strand copper wire: 40mm
Wooden:
Precisions mode: 20mm
Depth mode: 38mm
Automatic shut down: after 5 minutes without any operation
Battery: 1 * lithium battery, 300mAh (included)
Package size: 205 * 98 * 46mm / 8.1 * 3.9 * 1.8in
Package weight: 262g / 9.2ounce

Packing list:
1 * Wall Detector Scanner
1 * Manual
1 * Storage Bag
