SPECIFICATIONS

Brand Name: warmtoo

Humidification Method: ultrasonic

Power (W): 18w

Voltage (V): 24V

Noise: <36db

Origin: Mainland China

Capacity: <1L

Use: Household

Mist Outlet Quantity: One/a

Installation: Mini

Water-shortage Power-off Protection: No

Function: Ultrasonic Sterilize

Certification: ce

Model Number: SKU394476

Time to market: Aug-15

Humidifying Capacity: 250ml/h

Application: 11-20㎡

Humidity Control: Humidistat

Power Type: A.C. Source

Type: Ultrasonic Humidifier

Mist Output (gallon / day): 1

Shape: Other

Classification: Humidification

Timing Function: No

Operation Method: Keyboard Type

Pack Include:

Only Humidifier (Power adapter not included.)



Specifications
Operating voltage: 24 (V)
Power: 19 (W) (sign 1W)
Atomization amount:> 400cc / har
Operating frequency: 1700 ± 50 (KHZ)
Transducer plates diameter: 2cm
Effective level: 20mm ~ 75mm
Working temperature: 5 ~ 45  Celsius
Lantern: No light water level sensor switch:
Font door high H1.2cm
Atomizing head diameters: 4.5cm
High: 3.5cm
Plug Type: 5.5 × 2.1mm female plug
Suitable For:Family, air-conditioned rooms, beauty salons, hotels, hospitals, offices, kindergartens,
Kara OK rooms and other living spaces

How to use
1. Find a container mounted on the clean water, pure water is not available, the atomizing head flat on a container filled with water

2. Depth enough to cover the atomizing head side door black font 0.5-1.5CM appropriate level sensor, the water is too deep will not fog

3. Turn on the power, you can spray. Note that power is not splashed water



Note
1. A single spray head can not be used, must be equipped with 24V800MA power can be used.
2, the surface of the product is zinc alloy electroplating, spray head is made of plastic irrigation
sealants when cleaning the surface will scratch, but will not affect functionality. Please understand
that!
3, due to the atomizing head and the water temperature has a great relationship, beginning perhaps
we have not tried it on a picture so good results but after a few minutes or a little bit of hot water plus
the effect will be very good.
4, not too much water containers, or ineffective, the best level is 2-7CM, no more than the level of fog,
below this level will not fog or mist is very small
